For the emission calculation procedure Pollutant-Emis, the HGV share is required as input link attribute. The link attributes (air pollution) in Table 284 are output as output values.
|
Attribute |
Description |
|
Share of HGV (Input) |
Relevant HGV share in percent of total traffic (above 2.8 t total permissible weight) |
|
EDat NOx (Output) |
Nitric oxides in g/km |
|
EDat SO2 (Output) |
Sulphur dioxide in g/km |
|
EDat CO (Output) |
Carbon monoxide in kg/km |
|
EDat HC (Output) |
Hydrocarbons in g/km |
The Illustration 221 shows an example where the nitrogen monoxide volumes are displayed as link bars according to Pollution-Emis. In the User Manual you will find further information on implementation (User Manual: Displaying air pollution emissions).
Illustration 221: Display of nitrogen monoxide volumes as link bars
|
Note: For the display of pollution emissions, we recommend the use of classified values. |
